Inslogic PC-ABS Filament 1.75mm
Ships in 1 business day.
Free Shipping to most of USA, EU, UK regions.
100% Secure Payment and Transaction.
14 Days Return and Refund Service.
Choose options
Ships in 1 business day.
Free Shipping to most of USA, EU, UK regions.
100% Secure Payment and Transaction.
14 Days Return and Refund Service.
Ships in 1 business day.
Free Shipping to most of USA, EU, UK regions.
100% Secure Payment and Transaction.
14 Days Return and Refund Service.
- Excellent Thermal Stability: Withstands up to 102°C without deformation, ideal for high-temperature applications.
- Engineered Toughness – 70 KJ/m² Impact Tested: Durable and impact-resistant, ideal for printing load-bearing and high-impact 3D parts.
- Versatile Surface Finishes: 3D models printed with Inslogic PC-ABS support various post-processing techniques for enhanced durability and aesthetics.
- Polymer Composite Material: PC's Strength & Heat Resistance + ABS's Moldability.
- Applications: Automotive: Accessory mounts, handles, hooks, Electronics: Adapters, chargers, Functional prototyping, Tooling and gears
- Drying Settings: 70-80 °C, 6h
- Nozzle Size: 0.2, 0.4, 0.6 mm
- Nozzle Temperature & Printing Speed: 260-280 °C at 50-230 mm/s.
- Bed Temperature: 100 - 110 °C
- Cooling Fan Speed: 100%
- Bed Type: Textured PEI Sheet
* The settings displayed above are intended as guidance to help you find your optimal print settings. These ranges in settings should work for most printers. Each desktop 3D printer has its own characteristics and requires fine-tuning and optimization of these settings to achieve the best printing results.
Inslogic PC-ABS Filament is an engineering-grade material, compatible with FDM 3D printers using 1.75 mm diameter filament with a precision of ±0.03 mm.
Inslogic PC-ABS is an engineering-grade thermoplastic that combines the high heat resistance of polycarbonate (PC) with the toughness and processability of ABS. It is engineered for applications that demand strength, durability, and thermal stability.
With a heat deflection temperature of up to 102 °C and excellent impact resistance, Inslogic PC-ABS is well-suited for manufacturing functional prototypes, end-use components, and production-grade tooling. Its mechanical reliability makes it ideal for industries such as automotive, electronics, and industrial manufacturing.
Designed for both precision and performance, PC-ABS enables high-detail prints with an excellent surface finish. Whether you're producing wear-resistant prototypes or low-volume production parts, Inslogic PC-ABS filament delivers the durability and consistency required for professional-grade results.
- Length: 375 m
- Net Weight: 1 kg
- Diameter: 1.75 mm ± 0.03 mm
- Tensile Strength: 42 MPa
- Elongation at Break: 8.6%
- Flexural Strength: 72 Mpa
- Flexural Modulus: 2334 Mpa
- Density: 1.08 g/cm³
- Izod Impact, Notched: 70 KJ/m²
- Heat Deflection Temperature at 0.45 MPa: 103 ℃
------------------------
1 kg Reusable Spool Specifications:
- Materials: PC
- Color: White grey
- Temperature Resistance: ≤110℃
- Spool & Cardboard Coil Weight: 232 ± 3 g
- Inner Hole Diameter: 55±0.1 mm
- Outer Diameter: 200±0.1 mm
- Width: 67±0.1 mm
* All specifications have been tested in a laboratory. Please note that material properties may vary based on part geometry, print orientation, print settings, and temperature.
